RGB LED 8 Gang Switch Panel Kit Control Relay System with Automatic Dimmable

Preço normal$118.99
/
Envio calculado na finalização da compra.

LED Color

Este site está protegido pela Política de privacidade da reCAPTCHA e da Google e aplicam-se os Termos de serviço das mesmas.

  • Descriptions
  • Technical Data Sheet
  • Shipping & Returns
  • Reviews

Descriptions

About this item

【Unique 8-Gang Control】-The auto 8-gang switch panel presents an innovative solution for tidying up wiring, allowing centralized control of up to 8 sets of LED lights and accessories. With an operating voltage of 12-24V, a maximum power rating of 1200 Watts, and a maximum current rating of 60A, this powerful switch box ensures high sensitivity, stability, and strong anti-interference ability. Customize your panel with ease using the 50 self-adhesive labels included.

【Safety Design】-  The switch panel features an integrated overload protection system and a resettable 80 Amp circuit breaker. In case of high temperatures, it automatically disconnects for safety. Additional safety features include reverse polarity protection, over-voltage protection, and over-current protection, ensuring the safety of all connected LED lighting and accessories.

【Easy Installation】- Say goodbye to frustrating wiring with the plug-and-play wiring harness neatly organized in different color wires. The installation is a breeze, taking only about an hour. Two installation options allow placement in any desired position without the need to cut a large hole in your vehicle.

【Versatile Application】- Adopting IBGT (Insulated Gate Bipolar Transistor) technology, this universal switch control relay system is compact and fits perfectly into all 12V/24V DC power applications. Ideal for vehicles such as cars, trucks, jeeps, off-road, ATVs/UTVs, boats, marine vessels, Can-Am, Polaris, yachts, and caravans.

What’s in the package

1× 8 Gang Switch Panel

1× Switch Control Box

1× 80A Circuit Breaker

1× 50PCS Self-Adhesive Label

1× Mounting Bracket Kit

Strapping Tapes

Wiring Harness Set

Installation Instruction

Spec

Part NO PN-SP8100B
Operation Mode ON OFF
LED Color RGB
Rated Voltage 12V 20A/24V 10A
Operating Voltage 12V/24V
Maximum Power 1200W/600W
Maximum Current 60A
Operating Temperature  - 40° C ~ + 105° C
Panel Size 4.5in*2.59in*0.49in
Relay Box Size 4.7in*4.3.3in*1.33in
